Metallic and Non Metallic Magnetic Seal Less Pump
Characteristics and Design Features
- Single Stage, Horizontal Centrifugal Pump.
- Hydraulic Performance and Dimensions according to DIN EN ISO 2858
- Technical design based on DIN EN ISO 15783
- Permanent Magnet Drive
- Maintenance Free
- Separation of Liquid Chamber to Atmosphere by Means of Isolation Shell .Slipless Power Transfer
- Materials: Steel, Stainless Steel, Nickel Based Materials
- Close Coupled Block Design
- Hydraulically balanced impeller for minimum bearing loads
- Product-Lubricated Journal Bearings; made of Silicon Carbide (SiC) or Customized Materials
Operating Limits
Flow Rate | max 100m3/h |
Delivery Head | max 100 metre |
Pressure Rating | Class 150 |
Temperatures | -35°c to +250°c |
Applications
- Chemical Processing : basic and fine chemicals
- Agrochemicals, speciality chemicals
- Pharmaceuticals
- Biotechnology processing
- Food and beverage
- Pulp and Paper
- Refinery & Petrochemicals
- Metal processing
- Tanks storage
Casing & Impeller Materials
Characteristics and Design Features
Stainless steel SS 316, SS 316L, SS 304, SS 304L Othermaterials duplex alloys, nickel-base alloys (e.g.Hastelloy®),
Operating Limits
Working Principle | Radial flow pump |
Stages | Single Stage |
Sealing System | Magnetic Coupling |
Standards | DIN EN ISO 2858 |
Standards | DIN EN ISO 15783 |
Alax | 2014/34/EU |
